This post documents the debugging session from the early hours of March 22, 2026, collaborating with local AI Agent Antigravity to fix AgentBook on-chain registration on CanFly.ai.

Context

AgentBook is World’s on-chain agent registry — letting World ID-verified humans vouch for their AI Agents on Worldchain. The flow:

1. User clicks “Register to AgentBook”
2. Scans QR code with World App for ZK verification
3. Verification result returns to frontend
4. Frontend sends proof to backend relay
5. Relay calls the contract’s register() function

Sounds straightforward. But right after clicking the button:

Malformed bridge response payload

Not great.

Layer 1: Wrong Response Format

Inside worldIdBridge.ts, the error was thrown here:

// ❌ Original code
const data = await res.json()
if (!data.iv || !data.payload) {
  throw new Error('Malformed bridge response payload')
}

But the World ID Bridge returns a nested format:

// Waiting
{"status": "initialized", "response": null}

// World App scanned QR
{"status": "retrieved", "response": null}

// Verification complete — payload is inside response
{"status": "completed", "response": {"iv": "...", "payload": "..."}}

The code looked for iv and payload at the top level. Of course they weren’t there. The bridge returned 200, but since iv wasn’t at the root level, it was flagged as malformed.

Fix: Check data.status and only extract iv/payload from data.response when status is completed.

// ✅ Correctly parse nested format
if (data.status === 'initialized' || data.status === 'retrieved') {
  return null  // keep polling
}

if (data.status === 'completed') {
  const inner = data.response
  if (!inner?.iv || !inner?.payload) return null
  const decrypted = await decrypt(session.key, inner.iv, inner.payload)
  // ...
}

First layer peeled. ✅

Layer 2: Cloudflare Hijacks 502

After fixing the bridge parsing, World App scan succeeded, ZK proof decrypted successfully — great!

Then the frontend sent the proof to /api/agents/agentbook-register…

Unexpected token '<', "<!DOCTYPE "... is not valid JSON

The backend returned HTML? Turns out the backend relay to x402-worldchain.vercel.app/register failed and returned 502. Cloudflare Pages saw the 502 status code and replaced our JSON error response with its own HTML error page. The frontend tried res.json() on HTML. Crash.

Two fixes:

Backend: Return 500 instead of 502 to avoid Cloudflare interception:

// ❌ Intercepted by Cloudflare
return errorResponse(`Relay error: ${err}`, 502)

// ✅ Not intercepted
return errorResponse(`Relay error: ${relayText}`, 500)

Frontend: Use res.text() + JSON.parse instead of res.json():

const responseText = await res.text()
try {
  data = JSON.parse(responseText)
} catch {
  throw new Error(`Registration failed (${res.status}): server returned non-JSON response`)
}

Second layer peeled. ✅ Now we could finally see the actual error from the relay.

Layer 3: Signal Hash Mismatch

The relay returned 400 with detailed info:

The contract function "register" reverted with signature: 0x7fcdd1f4

Contract reverted. Found the source code on WorldScan:

function register(
  address agent, uint256 root, uint256 nonce,
  uint256 nullifierHash, uint256[8] calldata proof
) external {
  if (nonce != getNextNonce[agent]) revert InvalidNonce();

  worldIdRouter.verifyProof(
    root,
    groupId,
    abi.encodePacked(agent, nonce).hashToField(),  // ← look here!
    nullifierHash,
    EXTERNAL_NULLIFIER_HASH,
    proof
  );
}

The contract’s signal is hashToField(abi.encodePacked(agent, nonce)) — packing the agent address (20 bytes) and nonce (32 bytes) together before hashing.

But our frontend?

// ❌ Only sent agent address, no nonce!
const session = await createBridgeSession(
  APP_ID, ACTION,
  agentWalletAddress,  // ← missing nonce
)

World App generated a ZK proof with one signal. The contract verified against a different signal hash. Proof verification failed.

Fix: Use viem’s encodePacked to compute the exact same signal hash as the contract:

import { keccak256, encodePacked } from 'viem'

// ✅ Exactly matches contract's abi.encodePacked(agent, nonce).hashToField()
const packedSignal = encodePacked(
  ['address', 'uint256'],
  [agentWalletAddress as `0x${string}`, BigInt(nonce)]
)
const signalKeccak = keccak256(packedSignal)
const signalHash = `0x${(BigInt(signalKeccak) >> 8n).toString(16).padStart(64, '0')}`

const session = await createBridgeSession(
  APP_ID, ACTION,
  agentWalletAddress,
  window.location.href,
  signalHash,  // ← pre-computed signal hash
)

Third layer peeled. ✅

Result

Tried again — Agent registered on-chain! 🎉

Full flow:

initialized → retrieved → completed → decrypted → submit → ✅ on-chain

Three commits, three bugs:

Layer	Symptom	Root Cause
1	Malformed bridge response payload	Bridge returns nested {status, response} format; code looked at wrong level
2	Unexpected token '<'	Backend 502 replaced by Cloudflare HTML page; frontend res.json() crashed
3	Contract revert 0x7fcdd1f4	Signal hash used only agent address, missing packed nonce

Lessons

1. Read the contract source. Don’t assume signal format. AgentBook’s signal is abi.encodePacked(agent, nonce), not just an address. The contract source code is the only truth.

2. Cloudflare Pages intercepts 502. Don’t use 502 for your own error JSON — Cloudflare replaces it with its HTML error page. Use 500 or another status code.

3. Verify bridge API format yourself. World ID Bridge Protocol documentation is limited. Our pollBridgeOnce was based on IDKit source code, but the actual bridge response format ({status, response}) differs from IDKit’s internal handling. Log the raw response — always.

4. Add detailed logging. If we had logged the bridge’s raw response from day one, the first bug would’ve been a 5-minute fix. 90% of debugging is understanding what the problem actually is.

5. Peel one layer at a time. When three bugs stack on top of each other, the outermost error message has nothing to do with the actual root cause. Fix one layer, re-test, see the new error. Repeat until the onion has no more layers.

---

This post documents the real debugging process of integrating AgentBook on-chain registration on CanFly.ai. All API keys, private keys, and sensitive information have been replaced with placeholders.
